Einnovior performs Power Integrity Analysis to verify effective power distribution and power supply decoupling on a PCB. DC voltage drop can be assessed through power integrity analysis. Power integrity Analysis results can be further used in cost optimization of power supply components which is a significant cost for any product Design
DC Drop analysis
AC power plane analysis
Power/GND Impedance Profile Analysis
Return Current Path Analysis
De-coupling Capacitors Estimation
De-Caps Placement Planning
